JL Audio HD600/4
These Class D amplifiers use less power, take up less space, and generate less heat than traditional amp designs — you can even stack them up to create a sweet-looking installation.
HD Series amplifiers reproduce your music with exceptional accuracy, so you'll hear high-fidelity sound even under the most demanding conditions. JL Audio uses Single Cycle Control™ technology to eliminate the excessive signal distortion that's plagued Class D amplifiers in the past. Differential-balanced inputs eliminate noise before it hits the preamp stage, and allow you to connect the amp to just about any in-dash stereo. You'll hear clear, true, studio-quality audio, exactly what you expect from JL Audio.
General Features:
- 4-channel subwoofer amplifer
- 150 watts RMS x 4 (1.5 – 4 ohms per channel)
- 300 watts RMS x 2 bridged (3 – 8 ohms per channel)
- variable high- and low-pass filter (50-500 Hz 12 or 24dB/octave)
- subsonic filter and output polarity control
- removable power and speaker plugs
- optional wired remote for level control
- Class D amplifier design
- MOSFET power and output stages
- differential-balanced inputs eliminate noise from your vehicle's electrical system
- speaker- and preamp-level inputs
- preamp outputs
- 4-gauge power and ground leads and a 80-amp fuse recommended — wiring and hardware not included with amplifier
- 10-3/4"W x 2"H x 7-7/8"D
- no onboard fuses — when installing multiple amps in a system, an additional 80-amp in-line fuse between the distribution block and the amplifier is recommended
